Ring Blower GREENCO 2RB-733-1HY99 Series The performance curves are valid for pumping air at 15°C. at the inlet flanges with an air pressure of 1.013mbar and a tolerance of ±10%.The total pressure differences are valid up to an intake and ambient temperatrue of 25°C.
| Brand |
|---|
Blower GREENCO Single Stage Belt Drive 2RB-733-1HY99 Series
The performance curves are valid for pumping air at 15°C. at the inlet flanges with an air pressure of 1.013mbar and a tolerance of ±10%.The total pressure differences are valid up to an intake and ambient temperatrue of 25°C.
| MODEL | Rated Speed | Rated Power | Max Air Flow | Max Vacuum | Max Pressure | Sound-Level | Weight |
| RPM | KW | m3/h | mbar | mbar | dB(A) | Kg | |
| GREENCO 2RB-733-1HY99-1 | 3000 | 2.2 | 420 | -180 | 170 | 70 | 18 |
| 3600 | 2.55 | 500 | -160 | 150 | 73 | ||
| 4200 | 3 | 580 | -140 | 130 | 76 | ||
| 5000 | 3.8 | 660 | -120 | 120 | 81 | ||
| GREENCO 2RB-733-1HY99-2 | 3000 | 3 | 420 | -220 | 200 | 70 | |
| 3600 | 3.45 | 500 | -200 | 170 | 73 | ||
| 4200 | 4.3 | 580 | -180 | 170 | 76 | ||
| 5000 | 5 | 660 | -150 | 150 | 81 | ||
| GREENCO 2RB-733-1HY99-3 | 3000 | 4 | 420 | -260 | 290 | 70 | |
| 3600 | 4.6 | 500 | -260 | 260 | 73 | ||
| 4200 | 6 | 580 | -260 | 260 | 76 | ||
| 5000 | 6.9 | 660 | -260 | 240 | 81 |
