Ring Blower GREENCO 2RB-733-1HY99 Series

Ring Blower GREENCO 2RB-733-1HY99 Series The performance curves are valid for pumping air at 15°C. at the inlet flanges with an air pressure of 1.013mbar and a tolerance of ±10%.The total pressure differences are valid up to an intake and ambient temperatrue of 25°C.

Brand:

Ring Blower GREENCO 2RB-733-1HY99 Series

Blower GREENCO Single Stage Belt Drive 2RB-733-1HY99 Series

The performance curves are valid for pumping air at 15°C. at the inlet flanges with an air pressure of 1.013mbar and a tolerance of ±10%.The total pressure differences are valid up to an intake and ambient temperatrue of 25°C.

Ring Blower GREENCO 2RB-733-1HY99 Series



SPECIFICATION BLOWER GREENCO SINGLE STAGE BELT DRIVE 2RB-733-1HY99 SERIES

MODEL Rated Speed Rated Power Max Air Flow Max Vacuum Max Pressure Sound-Level Weight
RPM KW m3/h mbar mbar dB(A) Kg
GREENCO 2RB-733-1HY99-1 3000 2.2 420 -180 170 70 18
3600 2.55 500 -160 150 73
4200 3 580 -140 130 76
5000 3.8 660 -120 120 81
GREENCO 2RB-733-1HY99-2 3000 3 420 -220 200 70
3600 3.45 500 -200 170 73
4200 4.3 580 -180 170 76
5000 5 660 -150 150 81
GREENCO 2RB-733-1HY99-3 3000 4 420 -260 290 70
3600 4.6 500 -260 260 73
4200 6 580 -260 260 76
5000 6.9 660 -260 240 81
