Ring BlowerGREENCO 2RB-433-1HY99 Series The performance curves are valid for pumping air at 15°C. at the inlet flanges with an air pressure of 1.013mbar and a tolerance of ±10%.The total pressure differences are valid up to an intake and ambient temperatrue of 25°C.
| Brand |
|---|
Blower GREENCO Single Stage Belt Drive 2RB-433-1HY99 Series
The performance curves are valid for pumping air at 15°C. at the inlet flanges with an air pressure of 1.013mbar and a tolerance of ±10%.The total pressure differences are valid up to an intake and ambient temperatrue of 25°C.
| MODEL | Rated Speed | Rated Power | Max Air Flow | Max Vacuum | Max Pressure | Sound-Level | Weight |
| RPM | KW | m3/h | mbar | mbar | dB(A) | Kg | |
| GREENCO 2RB-433-1HY99 | 3000 | 1.3 | 180 | -180 | 200 | 64 | 8.5 |
| 3600 | 1.5 | 210 | -210 | 240 | 65 | ||
| 4200 | 1.75 | 255 | -240 | 230 | 69 | ||
| 5000 | 2.1 | 300 | -180 | 170 | 75 |
